Overview
This custom-engineered 8-port indoor distribution box is designed for FTTH applications to ensure rapid, organized, and maintainable fiber distribution within multi-dwelling units (MDUs).
Featuring plug-and-play capabilities, the enclosure comes pre-installed with a 1×4 splitter and can be scaled up to 8 ports by adding a second splitter upon request.
Flexible solution, practical application
Application Areas
- FTTH indoor distribution points
- As a floor distribution enclosure
- Termination and distribution hubs at building entrances
- Small to medium-scale internal cabling solutions
- Multi-dwelling buildings
- Outdoor facade mounting
- Pole mounting
- Last-mile distribution networks
Thanks to the proprietary Z-shaped fiber tray design inside, interventions for input and output ports are handled independently. This structure allows port-specific operations without compromising overall service continuity. Due to its ease of assembly and field flexibility, it is preferred by ISPs as a practical and reliable alternative for indoor premises solutions.
Product Details
| Malzeme | ABS |
| Renk | RAL7035 (Gri) |
| Giriş Portları | 2 Port |
| Çıkış Portları | 8 Port |
| Genişlik (W) | 202 mm |
| Yükseklik (H) | 257 mm |
| Derinlik (D) | 67 mm |
| Montaj | Vida ve Dübel Seti |
| Material | High-Impact ABS |
| Color | RAL7035 (Light Grey) |
| Input Ports | 2 Ports |
| Output Ports | 8 Ports |
| Width (W) | 202 mm |
| Height (H) | 257 mm |
| Depth (D) | 67 mm |
| Mounting | Screw and Wall Plug Set |
Technical Documents
AP08 Technical Datasheet
Click here to download the file.
AP08 Installation & User Guide
Click here to download the file.
